Small World Engine

Small World Engine is the "Preact of 3D Engines". It is an ultra-lightweight, high-performance, and strict TypeScript 3D game engine for the web. Built for the era of WebGPU and Playable Ads, it provides a modern Physically Based Rendering (PBR) pipeline and a robust Behavior System—delivering the architectural elegance of a real game engine at a fraction of the bundle size of traditional frameworks.

Read our full Vision & Strategy (VISION.md).

🚀 Features

• Hybrid PBR Rendering: High-performance rendering pipeline supporting WebGPU, WebGL 2, and WebGL 1 with industry-standard physically based shading (Cook-Torrance BRDF).
• Linear Lighting Workflow: All lighting calculations are performed in linear space with automatic sRGB gamma correction for realistic color falloffs and high visual fidelity.
• Advanced Materials: Includes standard PBR (Metallic/Roughness), but also physical Glass/Dielectric materials with real-time Screen-Space Refraction, Index of Refraction (IOR), and Beer's Law for volumetric light absorption.
• Advanced Camera System: Unified camera setup where controllers (e.g., OrbitController, FirstPersonController, ZoomController) are standard Behavior components attached via camera.addBehavior(). Features procedural effects like camera shake and flash.
• High-Performance Architecture: Optimized for memory efficiency through Object Pooling (MathPool), BindGroup & Pipeline Caching (WebGPU), and zero-allocation hot paths to eliminate Garbage Collection pressure.
• Lighting & Shadows: Supports Ambient, Directional, Point, Spot, and Area lights. Features robust Shadow Mapping (WebGL 2 & WebGPU) with Cascaded Shadow Maps, Hardware Shadow Sampling, and Percentage-Closer (Soft) Filtering (PCSS) for buttery-smooth soft shadows.
• Clustered Forward+ Lighting: The camera frustum is divided into a 3D grid of light-culling cells (WebGPU: compute-shader culled; WebGL 2: CPU-culled) so each pixel only evaluates the lights that actually reach it, raising the practical point/spot light budget well past a small fixed cap.
• Planar & Conformal Reflections: Real-time planar floor reflections (virtual mirror geometries) and dynamic sphere inversion reflections ($P' = C + V \cdot \frac{R^2}{d^2 - r^2}$) for PBR objects.
• Component Behaviors & State Machines: Robust, callback-driven behavior system to attach complex logic (FlickerBehavior, DeviceOrientationController, HoverBehavior, DraggableBehavior, etc.) directly to 3D objects, cameras, or materials. Includes a built-in, type-safe, zero-allocation Finite State Machine (FSM) framework to cleanly manage game actor lifecycles.
• Interactions & Gamification: A built-in InteractionManager allowing objects to instantly react to mouse/touch pointer events (onPointerEnter, onPointerClick, onPointerDown, onPointerMove, etc.). Pickable elements are queried via highly performant $O(\log n)$ Octrees and resolved to exact pixels via the Möller-Trumbore intersection algorithm.
• Stylized Post-Processing Pipeline: Built-in cinematic and retro filters (Phosphor Green Night Vision, Film Noir with chromatic aberration, Cyber Glitch, VHS Tape tracking, Amber/Sepia Underworld, Old Projector scratching/hair spots, and Thermal Vision), plus Bloom, a simplified screen-space ambient occlusion pass (HBAO), a simplified Temporal Anti-Aliasing pass (jitter + history blend), and a deliberate ghost/afterimage Motion Trail effect reusing the same history-blend machinery. Configured via static parameter specialization for optimal compilation without dynamic uniform cost.
• Scene Graph: Hierarchical scene management using a clean Object3D architecture.
• 2D/2.5D Support: First-class support for Sprites, Billboard rendering, and Pixel-Perfect Isometric perspectives.
• Audio System: Built-in AudioSystem with 3D Spatial Audio (HRTF), a procedural Retro Synthesizer (footsteps, lasers, drones, fire), and a built-in Mixer with procedural Reverb.
• Decoupled Architecture: Features a high-performance, strictly-typed global EventBus injected into all systems (this.events), separating Gameloop, Behaviors, and UI without relying on garbage-heavy DOM CustomEvent objects.
• Lightweight Physics System: A custom, impulse-based physics engine integrated directly into the PhysicsSystem. Supports RigidBodies with linear and angular dynamics (velocity, torque, inertia, damping), an Octree-broadphase, precise collision detection using the Separating Axis Theorem (SAT) for OBB vs. OBB and Spheres, realistic impulse resolution (bouncing/restitution) via Semi-Implicit Euler integration, fixed-timestep sub-stepping with render interpolation, Continuous Collision Detection (CCD) for fast-moving spheres, and FluidVolume zones for buoyancy/drag/current.
• Extensions Ecosystem: Includes modular drop-in utilities like the GridLevelBuilder to instantly generate complete dungeon levels from simple ASCII maps (["###", "#P#", "###"]).
• Geometry & Asset Loaders: Dynamic terrain generation, comprehensive primitive library, and async loaders for OBJ models, MTLLib materials, and textures (via unified static factories like Texture.fromUrl()).
• Hardware Telemetry & Feature Detection: Built-in DeviceCaps provides robust detection of WebGPU/WebGL API support, hardware limits (Memory, Cores, Texture Sizes), and experimental browser features (Wasm, Async, Generic Sensors).
• SPA & Frontend Framework Ready: Fully compatible with React, Vue, and Angular. Features a robust engine.destroy() lifecycle hook that completely frees GPU memory and detaches global event listeners. The engine even auto-destroys if it detects its canvas has been unmounted from the DOM.

⚡ Under the Hood (Hardcore Engineering)

• Zero-Allocation Render Loop: The critical path is strictly structured to ensure zero memory allocations (garbage) during the main render loop. This eliminates unpredictable Garbage Collection (GC) pauses, guaranteeing consistently smooth framerates.
• Custom Math Engine from Scratch: We don't rely on massive external math libraries like glMatrix. Small World features a bespoke, highly-optimized mathematics library for vectors and matrices, tailored exactly for our right-handed coordinate system.
• Advanced Rendering & Post-Processing: Consistent linear space math through the entire pipeline, featuring a highly efficient, unified final pass for Tone-Mapping, Color-Grading, Vignette, and sRGB Gamma Correction.
• Advanced Materials & Shaders: Built-in PBR, Retro Screen, and Fluid Surface materials (e.g. OpenWaterMaterial with Gerstner Waves and Opaque Depth-Fade for soft shores).
• WebGPU Compute Shaders: Real compute-shader usage, not just the graphics pipeline — e.g. the Clustered Forward+ Lighting pass culls every light against the frustum grid on the GPU before the main render pass runs.
• Automated GPU Memory Management: No more manual geometry.dispose() or material.dispose(). The engine utilizes rigorous internal reference counting across all renderers. When you remove an object from the scene, orphaned WebGL/WebGPU resources are safely and automatically garbage-collected.
• Absolute "Zero Dependency" Philosophy: No Three.js, no Babylon.js. We built a complete 3D engine—including Frustum Culling (frustum.intersectsVolume(obj.bounds)), Scene Graph, and Resource Management—entirely from scratch. This keeps the footprint tiny and performance at the absolute maximum.

📦 Installation

This package is private and not published to the NPM registry yet. Clone the repository and install dependencies locally:

git clone https://github.com/rottensteiner-stefan/small-world.git
cd small-world
npm install
Copy

🎮 Quick Start

The engine provides a SmallWorld base class that handles the render loop and hardware initialization automatically.

1. Configuration

You can configure the engine by passing an options object to the constructor. In modern bundlers (like Vite), you can also import a JSON file directly.

import config from "./config/small-world.json";

class MyGame extends SmallWorld {
  constructor() {
    // Pass the configuration to the engine
    super(config);
  }
// ...
Copy

2. Implementation Showcase

import { SmallWorld, Cube, Color, StandardMaterial, Object3D, OrbitController, Texture } from "small-world";

class MyGame extends SmallWorld {
  constructor() {
    super(); // Or pass config here
  }
  protected async setupScene(): Promise<void> {
    // 1. Load a texture and create a PBR material
    const albedoTex = await Texture.fromUrl("./assets/textures/diffuse.png");
    const geometry = new Cube({ size: 2 }).getGeometryData();
    const material = new StandardMaterial({
      map: albedoTex,
      color: Color.DODGERBLUE,
      metallic: 0.7,
      roughness: 0.2,
    });

    // 2. Wrap in an Object3D and add to scene
    const cube = new Object3D("MyCube");
    cube.geometry = geometry;
    cube.material = material;
    cube.position.set(0, 1, 0);

    this.scene.add(cube);

    // 3. Configure the camera and attach behaviors (controllers)
    this.camera.position.set(5, 5, 5);
    this.camera.target.set(0, 0, 0);

    // Camera controllers are now behaviors!
    this.camera.addBehavior(new OrbitController());
    this.camera.addBehavior(new ZoomController());
  }

  protected override update(deltaTime: number): void {
    // Logic executed every frame
  }
}

// Start the application
const game = new MyGame();
game.start();
Copy

🛠 Development

Prerequisites

• Node.js: We recommend using the version specified in .nvmrc. If you use nvm, simply run nvm use in the root directory.

Local Setup

1. Install dependencies:

   npm install
   Copy

2. Start development server (Vite):

   npm run dev
   Copy

3. Build the library:

   npm run build:lib
   Copy

Optional: Dev Containers (VS Code)

For an isolated development environment, this project includes a Dev Container configuration for VS Code.

• When opening the project, VS Code should prompt you to "Reopen in Container".
• This sets up the correct Node.js version and recommended extensions (ESLint, Prettier, etc.) automatically.

📂 Project Structure

• src/core: Core engine logic (SmallWorld, Object3D, Scene, Input, Color).
• src/core/behaviors: Modular runtime behavior components (e.g. Proximity Sensors, Oscillators).
• src/core/cameras: Camera strategies, projections, effects, and modular controllers.
• src/core/fsm: Type-safe, zero-allocation Finite State Machine utility.
• src/core/materials: Material definitions and PBR shader assets.
• src/core/lights: Light source implementations (Standard & PBR).
• src/geometry: Geometric primitives and terrain logic.
• src/math: Linear algebra, vectors, matrices, and object pooling.
• src/loaders: Asset loading pipeline (OBJ, MTL, Textures).
• src/renderers: Implementation of WebGL1, WebGL2, and WebGPU backends.
  • src/core/renderers/shaders/source: Core shader assets directly bundled with the engine.
• showcases: Interactive functional showcases demonstrating engine capabilities.
• public/assets, public/resources, public/tools: Static assets, shared resources, and the standalone browser-based generator tools (see below) used across showcases.

🧰 Tools

The engine includes several browser-based tools to help generate assets directly on the client side without relying on external software:

• The Forge (In-Game Overlay): A built-in window manager providing a suite of developer tools directly inside your game (toggle key is configurable, e.g. ~ or F12).
  • Pixler: A retro 2D pixel-art editor to draw and export sprites on the fly.
  • Xtractor: An image manipulation tool to crop, slice, and generate tile-maps or sprite atlases.
  • MapGenerator: A visual grid editor to paint ASCII levels for the GridLevelBuilder.
• PBR Map Generator (public/tools/pbr-gen.html): Generate Normal, Specular, AO, and Height maps from a single diffuse image.
• Splatter Generator (public/tools/splatter-gen.html): Generate procedural splatters and decals.
• IBL Generator (public/tools/ibl-gen.html): Generate Image-Based Lighting (Irradiance and Radiance) environment maps.

📚 Documentation

This project uses TypeDoc for automated API reference generation and VitePress for developer guides and tutorials.

1. Generate API Reference:

   npm run docs:api
   Copy

   This automatically extracts all classes, interfaces, and methods from the TypeScript source and generates a static HTML site under docs/public/api.

2. Start the VitePress Dev Server:

   npm run docs:dev
   Copy

   This serves the developer documentation locally. You can browse the guides and the newly generated API documentation.

📄 License

This project is licensed under the MIT License.
